Pharmaceutical Reactor Intermediate Manufacturing Process Reaction Vessels

Supply reaction vessel for pharmaceutical production, with reactor and mixer. customized.
We have wide range of Reaction Plants for Pharmaceutical Manufacturing Industry.


lab stainless-steel reactor ,pilot reactor,Stainless Steel pharmaceutical lab reactor
1.Capacity 5L-200L.
2.Including jacketed reactor,condenser,storage tank,conduction oil preheating tank,hot oil pump,pipelines,valves,temperature gauge PT100,pressure gauge,platform etc.
3.Made of SUS316L and SUS304.
4.Heating and cooling by jacket or heated by jacket and cooling by inner pipe coil.

Model selection reference of reaction kettle
Composition:     Instruction
Specification :   50L-50T
Design Pressure Mpa:  Atmospheric pressure or under pressure
Blending Power:  Model selection is made according to material viscosity, liquid-solid ration, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil
Stirring Blade Forms: Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type
Seal: Mechanical seal or stuff packing seal
Inner Surface Treatment: Polished or no polished
Discharge Valve: Flanged ball valve, open downward discharge valve and others
Technological Pipe Hole: Manhole, sight glass, distillation mouth, imported materials, pressure gauge port.
