Multifunctional Reactor for medium and high viscosity product 1

Multifunctional Reactor for medium and high viscosity product 2

Multifunctional Reactor for medium and high viscosity product 3

Multifunctional Reactor for medium and high viscosity product 4

Multifunctional Reactor for medium and high viscosity product 5

Multifunctional Reactor for medium and high viscosity product

MOQ:

1pcs

Place of Origin:

Guangdong,China

Payment Terms:

L/C, T/T, Westernunion, Paypal, Cash

Delivery Time:

3-30 working days depends on quantity

Accept Custom Service:

Yes

Certification:

CE / ISO9001:2015 / SGS

Inquiry

Write a Review

The reactor is widely used for reaction, evaporation, concentration, synthesization, extraction, polymerization, mineralization, etc.in chemical industry, medicine, dye, pesticide, organic synthesis, petroleum, food additives, industry of national defense and scientific research. Our company is an enterprise specialized in designing and manufacturing reaction kettles. With twenty years of experience in manufacturing reaction kettles, we can design and manufacture various types of reaction kettles for users.

*Structural principles:
Multifunctional reactor is integrations of high-speed disperser and low-speed stirrer, which is very suitable for medium and high viscosity product and Thixotropic material. Stirring and dispersing at the same time can proceed simultaneously and realize ideal effect. The multifunctional reactor is an ideal agitating and dispersing equipment which is easy to operate and widely applicable.

Model Selection Reference of Reactor

Composition	Instruction
Capacity	50L-10T
Heating Method	Steam heating, electrical heating, conduction oil heating by jacket
Cooling method	Water cooling, conduction oil cooling by inner coil or jacket
Design Pressure Mpa	Atmospheric pressure or under pressure or pressure tank
Blending Power	Model selection is made according to material viscosity, liquid—solid ration, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil
Stirring Blade Forms	Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type
Seal	Mechanical seal or stuff packing seal
Inner Surface Treatment	Polished or no polished
Discharge Valve	Flanged ball valve, open downward discharge valve and others
Technological Pipe Hole	Manhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature mouth, mouth filling N2, a gate, hot-carrier import and export of the cooling fluid, temperature measurement ports, sampling ports, emptying the mouth, according to the process above requirements increase or decrease.

Technical Specifications

Specification	FS-2	FS-3	FS-5	FS-6	FS-8	FS-10	FS-12
Capacity m³	2	3	5	6	8	10	12
Stirrer motor power kw	5.5	5.5	7.5	7.5	11	15	18.5
Stirring Speed r/min	50	50	50	50	41	41	41
Stirrer diameter mm	1300	1500	1700	1700	1900	2100	2300
Disperser speed r/min	960/1450	960/1450	960/1450	960/1450	960/1450	960/1450	750/1450
Disperser motor power kw	13/16	13/16	22/28	22/28	22/28	26/34	30/42
Disperser shaft quantity	2	2	2	2	2	2	2

Application

Multifunctional Reactor for medium and high viscosity product 6

Wooden paint

Multifunctional Reactor for medium and high viscosity product 7

Wooden paint
