Jinzong Machinery | Cosmetic Machinery & Chemical Machinery Manufacturers
Jinzong Machinery top measure tank volume suppliers for reflux
Company Advantages
1. Jinzong Machinery is scientifically designed. Basic knowledge such as Mechanics of Machines, Mechanics of Materials, Fluid Mechanics, Thermodynamics is used in its manufacture. Its frame is designed to reduce heat transmission
2. The product can greatly increase productivity. It will lead to a decrease in production time and an increase in output. The product can realize mobile feeding and output
3. The product features a clean appearance. It has been coated to enhance decontamination and prevent corrosion or foreign material contamination. The product has a strong bearing capacity for heavy materials processing
4. The product is highly reliable when it runs. It has no probability of failure when it operates for a long time at its rated capacity. The product can largely reduce waste materials
Company Features
1. We have employed a professional R&D team. They have years of experience in the development of new innovative products and at the time keep up with the trends.
2. With the company spirit of , Guangdong Jinzong Machinery Co., Ltd. practices the mission of creating value for costumers. Get quote!
1. Jinzong Machinery is scientifically designed. Basic knowledge such as Mechanics of Machines, Mechanics of Materials, Fluid Mechanics, Thermodynamics is used in its manufacture. Its frame is designed to reduce heat transmission
2. The product can greatly increase productivity. It will lead to a decrease in production time and an increase in output. The product can realize mobile feeding and output
3. The product features a clean appearance. It has been coated to enhance decontamination and prevent corrosion or foreign material contamination. The product has a strong bearing capacity for heavy materials processing
4. The product is highly reliable when it runs. It has no probability of failure when it operates for a long time at its rated capacity. The product can largely reduce waste materials
| Model NO. | S | Layout Type | Horizontal |
| Mixing Drum Shape | Disc | Additional Capabilities | Milling |
| Operating type | Continuous Operating | Condition | New |
| Machine Type | Mill | Warranty | 1 Year |
| Voltage | 380V,50Hz,3phase | Trademark | Jinzong Machinery |
| Transport Package | High Quality Plywood Cases of Export Standards | Specification | S65, S150, S260, S405 SM405 |
| Origin | Guangdong, China(Mainland), | HS Code | 8419899090 |
Product Description
Three Rollers Mill
is mainly used for paint, ink, plastic, paint, food and other paste materials, especially suitable for grinding high viscosity and particle size of fine products. Roll is made of chilled alloy cast iron centrifugal casting, so the crystal phase is closely, high strength, the surface has high hardness and wear resistance, and is provided with a cooling system.
The machine by rotating the handwheel adjustment of the horizontal direction of the three roller between the gap and the roller surface of jiga and different speed friction to grind dispersing effect.
Specification of three roller mill
Packaging & Shipping
1> Outer packing: plywood case
2> Inner packing: PE film wrapping overall
FOB port: Guangzhou or Shenzhen
Our Services:
Pre-sales service:
1> Engineering design
2> Equipment model selection guide
3> equipment machinig
After-sales service:
1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free.
2> Provide professional after-sales service engineers to abroad installation and debugging.
company information:
Guangzhou / Guangdong Jinzong Machinery Co., Ltd. is a professional manufacturer of cosmetic,chemical, biological & pharmaceutical machinery and equipment more than 20 years .
Jinzong Machinery is a technology innovative enterprise focusing on machinery design, manufacturing and system integration.
Product lines range from:
1> Cosmetic Machinery: water treatment ,vacuum emulsifying machine,liquid detergent mixing machine,storage tank,solid soap making machine,perfume making machine, color paste mill, filling machine etc.
2> Chemical Machinery: reactor, mixing equipment, separation equipment, storage tank, disperser, mill etc.
3> Biological and Pharmaceutical Machinery: vacuum ointment machine, fermentation tank, sanitary stainless reactor,alcohol deposition can, collocation tank etc.
is mainly used for paint, ink, plastic, paint, food and other paste materials, especially suitable for grinding high viscosity and particle size of fine products. Roll is made of chilled alloy cast iron centrifugal casting, so the crystal phase is closely, high strength, the surface has high hardness and wear resistance, and is provided with a cooling system.
The machine by rotating the handwheel adjustment of the horizontal direction of the three roller between the gap and the roller surface of jiga and different speed friction to grind dispersing effect.
Specification of three roller mill
| Model | S65 | S150 | S260 | S405 | SM405 | |
| Roller dia.(mm) | 65 | 150 | 260 | 405 | 405 | |
| Working length(mm) | 125 | 300 | 675 | 810 | 810 | |
| Speed | Slow(r/min) | 26 | 26 | 19.1 | 12.2 | 14.25 |
| Middle(r/min) | 70 | 70 | 54.5 | 37.6 | 44 | |
| Fast(r/min) | 145 | 145 | 155.3 | 116 | 135.5 | |
| Motor(kw) | 0.55 | 2.2 | 7.5 | 15 | 15 | |
| Size(mm) | 410×550×450 | 1010×930×1000 | 1645×1350×1100 | 2100×1950×1350 | 2290×1950×1350 | |
| Weight(kg) | 85 | 550 | 2200 | 5000 | 5200 | |
1> Outer packing: plywood case
2> Inner packing: PE film wrapping overall
FOB port: Guangzhou or Shenzhen
Our Services:
Pre-sales service:
1> Engineering design
2> Equipment model selection guide
3> equipment machinig
After-sales service:
1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free.
2> Provide professional after-sales service engineers to abroad installation and debugging.
company information:
Guangzhou / Guangdong Jinzong Machinery Co., Ltd. is a professional manufacturer of cosmetic,chemical, biological & pharmaceutical machinery and equipment more than 20 years .
Jinzong Machinery is a technology innovative enterprise focusing on machinery design, manufacturing and system integration.
Product lines range from:
1> Cosmetic Machinery: water treatment ,vacuum emulsifying machine,liquid detergent mixing machine,storage tank,solid soap making machine,perfume making machine, color paste mill, filling machine etc.
2> Chemical Machinery: reactor, mixing equipment, separation equipment, storage tank, disperser, mill etc.
3> Biological and Pharmaceutical Machinery: vacuum ointment machine, fermentation tank, sanitary stainless reactor,alcohol deposition can, collocation tank etc.
Why us?
1. Experienced workforce: more than 17 years
2. Excellent quality range of industrial process equipment ,80% materials and components are purchased from 3M, ABB, Siemens, Panasonic, Schneider
3. Strict quality controls
4. Good reputation in industry.
5. Customized packaging
6. Simple ordering process
7. Easy payment modes
8. Prompt delivery
9. Have a Professional after-sales service engineering team
Our Cutomers:
Over years, we have been serving American WILLOWTEX,Poland ANSER,Egypt ENDMOUN,Indian SWASTIK POLYMERS, Guangzhou Petrochemical Company, AKZONOBEL, Germany Henkell, Guangzhou Rubber, Daxing Hot Melt Glue, Bostik Findley, Forbo Bonding, Guangzhou Xiupo, China Paint and other more than thousand small and medium-sized enterprises, winning wide recognition and support from customers.
The introduction of highly advanced machines promotes the bulk production of mechanical equipment. The product is noted for its high precision.
Guangdong Jinzong Machinery Co., Ltd. has established a complete product system. The product is noted for its high precision.
Company Features
1. We have employed a professional R&D team. They have years of experience in the development of new innovative products and at the time keep up with the trends.
2. With the company spirit of , Guangdong Jinzong Machinery Co., Ltd. practices the mission of creating value for costumers. Get quote!
