High speed dispersing reactor
Chemical Machine FS series Multifunctional Mixing Dispersing Tank is integrations of powerful mixer and high speed disperser, which is applicable for mixing, dispersing, dissolution and color mixing of medium/high viscosity and thixotropy materials. Mixing and dispersing can proceed simultaneously and reach ideal effect. It is ideal mixing and dispersing equipment which is easy to operate and widely applicable.
FS-2 | FS-3 | FS-5 | FS-6 | FS-8 | FS-10 | FS-12 | ||
Volume of Tank(m 3 ) | 2 | 3 | 5 | 6 | 8 | 10 | 12 | |
Power of Mixing Motor(kw) | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | 18.5 | |
Speed of Mixing Shaft(rpm) | 50 | 50 | 50 | 50 | 41 | 41 | 41 | |
Dia. of Mixer Blade(mm) | 1300 | 1500 | 1700 | 1700 | 1900 | 2100 | 2300 | |
Power of Dispersing Motor(kw) | 13/16 | 13/16 | 22/28 | 22/28 | 22/28 | 26/34 | 30/42 | |
Speed of Dispersing Shaft(rpm) | 960/1450 | 960/1450 | 960/1450 | 960/1450 | 970/1470 | 970/1470 | 750/1480 | |
Qnty. of Dispersing Shaft | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
Dimension(mm) | D | 1400 | 1600 | 1800 | 1800 | 2000 | 2200 | 2400 |
H | 1650 | 1765 | 2048 | 2400 | 2800 | 2950 | 3100 | |
H1 | 1930 | 2000 | 2200 | 2200 | 2500 | 2570 | 2620 | |
