high-quality ross machine manufacturers for reflux
| Trademark | JINZONG | Transport Package | Wooden Case |
| Specification | SUS304, 316L | Origin | Guangdong |
| HS Code | 8474900000 |
Automatic Ointment Cream Paste & Liquid Emulsifying mixing machine
Available capacity: 20 Liter to 20000 Liter
Project case
JINZONG MACHINERY, manufacturers Automatic Ointment/Cream/ Toothpaste and Liquid manufacturing/ process plants, as per customer requirements, complete with Main manufacturing vessel, associate water phase, wax phase vessel, and sugar melting vessel in case of Liquid plants, thoroughly steam jacketed in heavy duty construction, with Mechanical seals at the bottom homogenizer, and top stirrers with automatic top dish opening mechanism and automatic batch weighing systems.
Available capacity: 20 Liter to 20000 Liter
Product Description
Automatic pharmaceutical Ointment Cream paste & Liquid making plant consist the following equipments and accessories:
Water Phase Vessel
Wax Phase Vessel
Batch Manufacturing Vessel
High speed homogenizer & emulsifier
Transfer pumps
Storage Vessel
Control Panel
Product Piping
Working Platform
BASIC DESIGN FEATURES & OPERATION:
Entire plant consist of a closed circuit manufacturing facility from feeding of Wax / Water Phase / Ingredients up to loading into Filling Machine.
The Water is metered & loaded using Flow meter for precise feeding.
Both water & wax phase vessels are jacketed for heating & equipped with suitable stirrer & disperser. The Main Batch Vessel is fitted with Slow speed Main agitator for blending & distribution effect & also supported by additional high speed homogenizers. Heating & Cooling provision thru jacket is there. In typical process demand, Online Homogenizer can also be provided for fine texture of end product. In main Batch Mixer, Mixing & other process is achieved using vacuum to avoid air entrapment. The Cream prepared is transferred to Storage Vessel by transfer pump.
Various type of Mixer are fabricated as per product used viz. Double Contra Rotary Mixer, Fixed Baffle Mixer etc.
Automatic pharmaceutical Ointment Cream paste & Liquid making plant consist the following equipments and accessories:
Water Phase Vessel
Wax Phase Vessel
Batch Manufacturing Vessel
High speed homogenizer & emulsifier
Transfer pumps
Storage Vessel
Control Panel
Product Piping
Working Platform
BASIC DESIGN FEATURES & OPERATION:
Entire plant consist of a closed circuit manufacturing facility from feeding of Wax / Water Phase / Ingredients up to loading into Filling Machine.
The Water is metered & loaded using Flow meter for precise feeding.
Both water & wax phase vessels are jacketed for heating & equipped with suitable stirrer & disperser. The Main Batch Vessel is fitted with Slow speed Main agitator for blending & distribution effect & also supported by additional high speed homogenizers. Heating & Cooling provision thru jacket is there. In typical process demand, Online Homogenizer can also be provided for fine texture of end product. In main Batch Mixer, Mixing & other process is achieved using vacuum to avoid air entrapment. The Cream prepared is transferred to Storage Vessel by transfer pump.
Various type of Mixer are fabricated as per product used viz. Double Contra Rotary Mixer, Fixed Baffle Mixer etc.
Application:
Cosmetic Industry: Cream, Lotion, Lipstick, Shampoo
Pharmaceutical Industry: Ointment, Syrup, Injection
Food Industry: Mayonnaise, Dressing, Jam, Butter, Margarine.
Chemical Industry: Polyester, Synthetic fiber
Paint Industry: Paints, Synthetic resin paint
Others: Color, Wax, Shoe cream, Coating liquid
Pharmaceutical Industry: Ointment, Syrup, Injection
Food Industry: Mayonnaise, Dressing, Jam, Butter, Margarine.
Chemical Industry: Polyester, Synthetic fiber
Paint Industry: Paints, Synthetic resin paint
Others: Color, Wax, Shoe cream, Coating liquid
Project case
JINZONG MACHINERY, manufacturers Automatic Ointment/Cream/ Toothpaste and Liquid manufacturing/ process plants, as per customer requirements, complete with Main manufacturing vessel, associate water phase, wax phase vessel, and sugar melting vessel in case of Liquid plants, thoroughly steam jacketed in heavy duty construction, with Mechanical seals at the bottom homogenizer, and top stirrers with automatic top dish opening mechanism and automatic batch weighing systems.
This product has a wide range of applications on the market. The product can largely reduce waste materials.
This product has many excellent properties and is suitable for various fields. The product can largely reduce waste materials.
