high-quality labeling machinery for business
Company Advantages
1. The manufacture of Jinzong Machinery labeling machinery is based on the production technology, which is an international leading level. The product works very smoothly and causes less noise
2. This product helps to enhance the performance of the operator. Not only will it enhance the overall work precision, but also it will reduce the number of operations. The product has a strong bearing capacity for heavy materials processing
3. The product stands out for its durability. Its lamp shade features strong shock resistance to allow the light work well even in bad condition. It is highly resistant to UV light and flame
4. The product is not subject to deformation under high temperature. The steel material used in it contains a high content of chromium and nickel which have excellent creeping strength, hence, it is heat-resisting. The product has passed the CE certification
Automatic labeling machine,Double Side and Round Bottle Labeling Machine,flat bottles labeling machine
1.Working Principle:
Put the bottles on the conveyor Bottles separating arrange/leading bottles
Labeling press labels finshed
2.automatic labeling machine Structure:
Main Motor: 750W Panasonic servo motor, Panasonic servo amplifier ,Danfoss frequency inverter , Siemens PLC ,Siemens touch screen ,German LEUZE labels sensor ,Japan KEYENCE FS-V11 optoelectronic switch
Conveyor:Motor 750W,speed adjustable by frequency inverter.
Bottles leading structure: Double coordinate adjustment stainless steel rail.
Bottles separating:Panasonic motor,speed adjustable.
Plastic parts of the structure:Panasonic motor,speed adjustable,with the mechanical synchronous speed of the conveyor.
Press belt structure:Spiral Bevel Gear Drive,with the mechanical synchronous speed of the conveyor.
Scraper:Sponge spring steel plate combination.
Labels press structure :Combination unpowered sponge roller,Quick disassembling structure for different size of labels..
3.Parameter:
automatic labeling machine Labels direction
Photos of the labeling machine:
Company Features
1. High quality of labeling machinery helps Guangdong Jinzong Machinery Co., Ltd. occupy big global market. can labeling machine is exceptionally qualified in the market.
2. All the projects Guangdong Jinzong Machinery Co., Ltd. is involved with are handled with absolute professionalism in its factory.
3. Jinzong Machinery has been focusing on improving the quality of shrink sleeve label machine . Our business goal is to be a dependable company across the world. We achieve this by deepening our techniques and strengthening the satisfaction of our clients.
1. The manufacture of Jinzong Machinery labeling machinery is based on the production technology, which is an international leading level. The product works very smoothly and causes less noise
2. This product helps to enhance the performance of the operator. Not only will it enhance the overall work precision, but also it will reduce the number of operations. The product has a strong bearing capacity for heavy materials processing
3. The product stands out for its durability. Its lamp shade features strong shock resistance to allow the light work well even in bad condition. It is highly resistant to UV light and flame
4. The product is not subject to deformation under high temperature. The steel material used in it contains a high content of chromium and nickel which have excellent creeping strength, hence, it is heat-resisting. The product has passed the CE certification
| Model NO. | JZ-AL-9180 | Packaging | Bottles |
| Power | 3kw | Voltage | 220V,50/60Hz or Customer Design |
| Labeling Speed | 0-12000PCS/H | Trademark | JNZONG MACHINE |
| Transport Package | Plywood Case Wooden | Specification | CE, SGS |
| Origin | China |
Automatic labeling machine,Double Side and Round Bottle Labeling Machine,flat bottles labeling machine
1.Working Principle:
Put the bottles on the conveyor Bottles separating arrange/leading bottles
Labeling press labels finshed
2.automatic labeling machine Structure:
Main Motor: 750W Panasonic servo motor, Panasonic servo amplifier ,Danfoss frequency inverter , Siemens PLC ,Siemens touch screen ,German LEUZE labels sensor ,Japan KEYENCE FS-V11 optoelectronic switch
Conveyor:Motor 750W,speed adjustable by frequency inverter.
Bottles leading structure: Double coordinate adjustment stainless steel rail.
Bottles separating:Panasonic motor,speed adjustable.
Plastic parts of the structure:Panasonic motor,speed adjustable,with the mechanical synchronous speed of the conveyor.
Press belt structure:Spiral Bevel Gear Drive,with the mechanical synchronous speed of the conveyor.
Scraper:Sponge spring steel plate combination.
Labels press structure :Combination unpowered sponge roller,Quick disassembling structure for different size of labels..
3.Parameter:
Item | Specification | |
1 | Labeling head number | 2pcs |
2 | Labels type | Adhesive sticker |
3 | Weight(height) of labels transporter | Max:200mm |
4 | Length of labels transporter | Max:400mm |
5 | Scraper | 20-200mm |
6 | Dimension of labeling object | thickness≤90mm height≤450mm or customer design |
7 | Labeling speed | 30-50m/min |
8 | Conveyor speed | 0-30m/Min |
9 | Capacity | 0-12000pcs/h |
10 | Tap location precision | ±0.2mm |
11 | Labeling precision | ±1mm |
12 | Label plate outside diameter | 350mm |
13 | Label plate inside diameter | 76.2mm |
14 | Qty of label plate | 2pcs |
15 | Size of Labels collector | 180mm |
16 | Method of labels collector | Rewind the labels |
17 | Conveyor belt | 950±50mm |
18 | Net weight | 500kg |
19 | Bottles conveying direction | From left to right |
20 | Labels conveying direction | From left to right |
21 | Dimension | L3048*W1400*H1650(mm) |
22 | Power supply | 220V/50Hz 3000W |
Application labels | |
Raw material of labels: | All the paper type labels,thin film type labels |
Thickness of labels: | >2.5mm |
The material of bottom labels: | Enough pull,the glassine or PET bottom labels will be better. |
Label spacing requirement | Minimum spacing is 2.54mm,standard spacing is 3mm |
Label size allowed error | ±0.3 mm |
Max weight of labels: 200mm | < 200mm |
automatic labeling machine Labels direction
4.Main Components: | |||||
Name | Item | Brand | Country | Units | Qty |
PLC | S7-224 | Siemens | German | set | 1 |
Touch Screen | Siemens | Taiwan | set | 1 | |
Servo driver | MCDDT3520003 | Panasonic | Japan | set | 2 |
Servo driver | MHMDD082P1U | Panasonic | Japan | set | 2 |
Frequency inverter | FC-051PK | Danfoss | Danmark | set | 2 |
a.c. contactor | LC1-D2510M7N | TELEMECANIQUE | German | set | 1 |
Urgent stop switch box | 54*54 | TELEMECANIQUE | German | pcs | 1 |
Urgent stop switch | XB2 ES542 | TELEMECANIQUE | German | pcs | 1 |
Object sensor | FS-V11 | KEYENCE | Japan | set | 1 |
Label sensor | GS63/6D.3-S8 | LEUZE | German | pcs | 2 |
Power switch | 24V 6A | Meanwell | Taiwan | set | 1 |
Conveyor motor | GV28-750-25S | Wanxin | Taiwan | set | 1 |
Motor | M9MC60G4Y | Panasonic | Japan | set | 1 |
Transmission | MGC30B | Panasonic | Japan | set | 1 |
Speed controller | (includes insurance switch) | Panasonic | Japan | set | 1 |
Photos of the labeling machine:
Supported by the industry's knowledgeable technicians and customer service team, Jinzong Machinery wins great reputation since founded. The product has the advantage of low energy consumption.
Whatever the occasion, Jinzong Machinery captures the attention of chemical reactor in this field. The product has the advantage of low energy consumption.
Company Features
1. High quality of labeling machinery helps Guangdong Jinzong Machinery Co., Ltd. occupy big global market. can labeling machine is exceptionally qualified in the market.
2. All the projects Guangdong Jinzong Machinery Co., Ltd. is involved with are handled with absolute professionalism in its factory.
3. Jinzong Machinery has been focusing on improving the quality of shrink sleeve label machine . Our business goal is to be a dependable company across the world. We achieve this by deepening our techniques and strengthening the satisfaction of our clients.
