custom coating pan machine for business
1. The design of Jinzong Machinery is strictly conducted. It is carried out by our designers who think highly of parts and components safety, the whole machine safety, operation safety, and environmental safety. The product has the merit of full traceability
2. Perfect quality control systems insure high quality and reliability of coating pan machine products. The product is very easy to maintain
3. It has great strength. Appropriate material is selected individually for its component based on the analysis of stresses that work upon these components. It is resistant to breakage with its sturdy frame
4. The product features low power or energy consumption. The product, with a compact design, adopts the most advanced energy-saving technology. The product works under an effective ERP system
5. This product has a best-suited shape. Its dimensions are calculated based on the loads on its elements and strength of the material. The product has high sensitivity to quickly respond to users' operation
| Model NO. | FL | Layout Type | Verticle |
| Mixing Drum Shape | Disc | Additional Capabilities | Milling |
| Operating type | Continuous Operating | Condition | New |
| Power(W) | 2.2kw-90kw | Voltage | 380V/50Hz |
| Warranty | 1 Year | Trademark | Jinzong Machinery |
| Transport Package | High Quality Plywood Cases of Export Standards | Specification | Prevail |
| Origin | Guangdong, China (Mainland) | HS Code | 8474390000 |
It has two types FL and FX according to different installation
Features:
Stepless variable speed
Explosion- proof Electric box, Explosion- proof motor, Explosion- proof travel switch
Superior performance
It is widely used in coating , oil, ink ,resin, adhesive, medicine,pigment dfood industry etc.are widely used in papermaking, dye and pigment, paint and coating, electronics, ink, Chemical, food and
Technical Information:
FL/FX Type High Speed Disperser
| Type | FL2.2/3/4 | FL5.5/7.5/11 | FL15/18.5/22 | FL30/37/FX37 | FL45/FX45 | FL90/FX90 |
| Motor power(kw) | 2.2/3/4 | 5.5/7.5/11 | 15/18.5/22 | 30/37/37 | 45 | 45 |
| Split shaft speed bulk(r/min) | 0-1450 | 0-1450 | 0-1450 | 0-1200 | 0-1200 | 0-1000 |
| Wheel dia. Of disperser(mm) | 200 | 250 | 300 | 350-400 | 450 | 600 |
| Rack lift travel(mm) | 700 | 900 | 1200 | 1200 | 1600 | 1600 |
| Pump power(kw) | 0.55 | 0.55 | 0.75 | 0.75 | 1.1 | 2.2 |
| Cylinder volume of material(L) | 100-200 | 400-600 | 600-1000 | 1000-2000 | 1000-2500 | 5000 |
| Weight(kg) | 400 | 800 | 1500 | 1700 | 2100 | 2600 |
| Dimensions(mm) | A | 1700 | 1750 | 2200 | 2600 | 2700 |
| B | 1300 | 1800 | 2100 | 2700 | 3000 | |
| C | 600 | 900 | 1100 | 1400 | 1600 | |
| W(with) | 540 | 350 | 900 | 1000 | 1500 |
The series of equipment are applied to the dissolution, mixing and dispersion of materials in many industries such as painting, dyestuff, pigment, medical, papermaking and other industries. The equipment is characterized by minimum include air during mixing and dispersion, perfect solid-liquid mixing and dispersion effect, and fast dissolution and fine particles during high-and medium-speed dispersion process.
Our Service:
Pre-sales service:
1> Engineering design
2> Equipment model selection guide
3> equipment machinig
After-sales service:
1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free.
2> Provide professional after-sales service engineers to abroad installation and debugging.
Company information:
JINZONG INTERIPRISE is a technology innovation enterprise for integrating design, manufacturing and system integration of cosmetic machinery & equipment with 20 years experiences. It has over 20,000 square meters production base; Guangzhou jinzong its covers an area of 8,000 squre meters, Guangdong jinzong its covers an area of 17,000 square meters, and jinzong has been service over 2,000 customer around the world.
Why us?
1. Experienced workforce: more than 17 years
2. Excellent quality range of industrial process equipment ,80% materials and components are purchased from 3M, ABB, Siemens, Panasonic, Schneider
3. Strict quality controls
4. Good reputation in industry.
5. Customized packaging
6. Simple ordering process
7. Easy payment modes
8. Prompt delivery
9. Have a Professional after-sales service engineering team
Certification
Company Features
1. The technology level for coating pan machine is high enough.
2. Guangdong Jinzong Machinery Co., Ltd. continuously improves and perfects the integrated design manufacturing service process in order to become a differentiated international company. Please contact us!
