PVA Emulsions Plant
Jinzong Machinery | Cosmetic Machinery & Chemical Machinery Manufacturers
professional jacketed reactor Chinese
MOQ:
1pcs
Place of Origin:
Guangdong,China
Payment Terms:
L/C, T/T, Westernunion, Paypal, Cash
Delivery Time:
3-30 working days depends on quantity
Accept Custom Service:
Yes
Certification:
CE / ISO9001:2015 / SGS
Product Comparison
Under the guidance of market, Jinzong constantly strives for innovation. mechanical equipment has reliable quality, stable performance, good design, and great practicality.Jinzong's mechanical equipment has the following advantages over other similar products.
Enterprise Strength
- Jinzong answers all kinds of customer's questions with patience and provides valuable services, so that customers can feel respected and caring.
1. Jinzong Machinery condenser is strictly scrutinized. It has gone through the on-line monitoring for its technological parameter, such as its dyeing saturability, weaving fineness, fabric strength, etc.
2. The product has high dirt and contaminant removal efficiency. The filter system including the polyporous activated carbon and membrane can absorb the harmful small molecule and macromolecular compound.
3. The product is durable in use. The use and abuse testing of this product are available to verify that it can be collected for a long time.
4. The scale of the product application is gradually increasing.
5. The product adapts to market need and is widely used at home and abroad.
The reactor is widely used for reaction, evaporation, concentration, synthesization, extraction, polymerization, mineralization, etc.in chemical industry, medicine, dye, pesticide, organic synthesis, petroleum, food additives, industry of national defense and scientific research. Our company is an enterprise specialized in designing and manufacturing reaction kettles. With twenty years of experience in manufacturing reaction kettles, we can design and manufacture various types of reaction kettles for users.
*Product Function Brief:
A. Operating principle: Break down or recombined the materials through mixing, filling and cooling, to promote the reaction of polymerization.
B. Components: Body, gears, mixing devices, heating devices, cooling devices, seal, etc.
C. Auxiliary Equipment: Distillation column, head tank, condenser, water separator, collecting cans, filters, etc.
D. Widely used in: Resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.
E. Applicable Field: All the liquid-liquid, liquid-powder reaction industry.
Model Selection Reference of Reactor
| Composition | Instruction |
| Capacity | 50L-50T |
| Heating Method | Steam heating, electrical heating, conduction oil heating by jacket |
| Cooling method | Water cooling, conduction oil cooling by inner coil or jacket |
| Design Pressure Mpa | Atmospheric pressure or under pressure or pressure tank |
| Blending Power | Model selection is made according to material viscosity, liquid—solid ration, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil |
| Stirring Blade Forms | Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type |
| Seal | Mechanical seal or stuff packing seal |
| Inner Surface Treatment | Polished or no polished |
| Discharge Valve | Flanged ball valve, open downward discharge valve and others |
| Technological Pipe Hole | Manhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature mouth, mouth filling N2, a gate, hot-carrier import and export of the cooling fluid, temperature measurement ports, sampling ports, emptying the mouth, according to the process above requirements increase or decrease. |
Stirring Blade Forms Selection
Mixing system is the core component of reactor, a custom-made stirrer is your key to success. Stirrer selection is related with the material’s viscosity, liquid-solid ratio, proportion of liquid, solid’s weight, solid’s particle size, blade type, rotating speed, baffle, internal pipe coil etc.
Technical Specifications
| Specifications (L) | Cylinder size (mm) | Actual volume (L) | Jacket volume (L) | Heating area (㎡) | Motor Power (kw) | Speed (r/min) | Discharge valve |
| 50 | 450*450 | 61 | 65 | 0.78 | 0.55 | 85 | DN25 |
| 100 | 450*500 | 150 | 120 | 1.36 | 1.1 | 85 | DN25 |
| 200 | 600*700 | 253 | 200 | 1.9 | 1.5 | 85 | DN40 |
| 300 | 750*750 | 396 | 250 | 2.41 | 2.2 | 85 | DN40 |
| 500 | 900*800 | 699 | 290 | 2.7 | 3 | 85 | DN50 |
| 1000 | 1200*1000 | 1393 | 560 | 4.5 | 4 | 85 | DN50 |
| 1500 | 1300*1200 | 2166 | 617 | 5.9 | 5.5 | 85 | DN50 |
| 2000 | 1400*1500 | 3000 | 750 | 7 | 5.5 | 85 | DN65 |
| 3000 | 1600*1500 | 4066 | 1050 | 9 | 7.5 | 63 | DN65 |
| 4000 | 1700*1800 | 5400 | 1226 | 11 | 11 | 63 | DN80 |
| 5000 | 1800*2000 | 6600 | 1440 | 12.8 | 11 | 63 | DN80 |
Application
*Application of Reaction plant:
The whole set of equipment includes reactor, vertical fractionating column, horizontal condenser, water storage tank, oil spill tank and piping (dilution kettle). All parts of the equipment that contact with the material are all made by stainless steel.
*Model selection reference of resin production equipment:
| Composition | Instructions |
| Main Reactor | The size, material, heat transfer systems, mixing systems, sealing systems of reactor according to client's specification |
| Dosing Vessel | According to the client's demand, it adopts gravity tank, gravity mixing tank, gravity dispersing tank, gravity emulsifying tank. |
| Distillation Device | Vertical condenser, horizontal condenser and separator. |
| Vacuum system | All kinds of vacuum pumps, buffer tanks. |
| Thinning Vessel/cooling tank | The size, material, heat transfer systems, mixing systems, sealing systems of thinning vessel according to client's specification |
| Pipeline system | According to the client's demand, it decides the heating, cooling, vacuum and material pipelines, and including related valves, flowmeters and expanders etc. |
| Control System | According to client's demand, it decides manual, semi-automatic or full-automatic system. |
| Filter System | Frame filter, bag filter or centrifuge etc. |
| Operation Platform | Steel platform or concrete platform |
Ink Production
Insulation Paint Production
Resin Production
Qualification certificate
We carry out products designing, manufacturing, assembling and detection fully in accordance with ISO9001-2015 Quality Management System issued by Swiss SGS Company.
Company Features
1. Guangdong Jinzong Machinery Co., Ltd. has a wide selection of condenser to suit your needs.
2. Superb processing level for packing column is acquired by Guangdong Jinzong Machinery Co., Ltd..
3. Although as a small and medium-sized enterprise, Guangdong Jinzong Machinery Co., Ltd. has been striving to be the best chemical filling machine supplier. Inquiry! Excellence in quality of automatic control system and being professional in service are what Jinzong Machinery wishes. Inquiry!
SHENGLIN Shanghai well designed Industrial water cooled condenser and evaporate price
feature:
1.Braze welding vs expanded tube joint
2.Metallic bonding between Micro channel tubes and fin.
3.Off the shell high performing split a/c system was examined in ARI conditions A,B and C with two condensers: microchannel flat plate fin.
4.Condenses had the same volume, face, and air side area.
5.Microchannel condenser performed better and consequently system performed better.
6.Average increase in capacity is 4% and in COP IS 17% simuitaneously.
7.Charge reduction is 19% for the condenser and 9% for the system.
8.The MCHX has better corrosion resistance
9.The MCHX is built to last
10.Area available for heat transfer in microchannel HX
washer dryer condenserer advantage:
1.Brazed Aluminum construction
2.Combination welded cores-Air&Oil cores
3.Brazed aluminum core/bar and plate
4.Excellent for field conversions
5.Compact design
6.Light weight
7.State-of-the-art heat transfer technology
8.Compact,high performance all aluminum core assembly
9.Designed specifically for rotary screw compressor
10.Eliminates high water and sewer costs
If you have do not which model is suitable for you please tell me the below information .
Then we can help you and save time for you.
This for all most heat exchanger:
washer dryer condenserer pictures:
washer dryer condenserer policy:
1. We charge for samples. If we have the samples you need in stock, we can send it to you within one week after received payment.
2. We can also manufacture samples according to your drawings or samples; lead time depends on the actual production status in our factory.
Choose Us; Do Not Hesitate:
1) We can help buyers design specific products or produce products according to buyers' design
2) We can print logo according to buyers' requirement
3) We has exported to many countries,such as Korea, USA, German, Canada etc.
4) Design term:We have professional design team.
5) Professional factory: We are manufacturer, specializing in manufacturing heat exchangers for over 10 years, competitive price with good quality.
6)Large productivity: 2000opcs per month.
7)Rapid response to your needs: We will reply within 24 hours after receiving you letter. If you have urgent thing, welcome to call us.
8)The Most Efficient Service, Best Quality and Excellent Reputation.
Note: for further information please contact me.
Ms. Echo Li
Tel: +86 21 35324169-206
Mob: +86 138187996746
Skype: sales9shenglintec.com
Product Description
refrigeration condensing unit with open type compressor for air cooling
- We have 21 years professional condensing unit manufacture experience.
- We possesses state-scale sales net.
- we are a powerfull supplier for many trading company and distributors for condensing unit export(commercial use,cold store room etc.)
- CE,RoHS:green channel for Europe market,trustworthy quanlity.
- reputable afterservice
