Model NO. | 500tons-15, 000 tons | Layout Type | Verticle |
Mixing Drum Shape | Disc | Additional Capabilities | Milling, Coating |
Operating type | Continuous Operating | Condition | New |
Machine Type | Mill | Warranty | 1 Year |
Voltage | 380V,50Hz,3phase | Trademark | Jinzong Machinery |
Transport Package | High Quality Plywood Cases of Export Standards | Specification | FD45, FD55, FD75, FD90, FD110, FD132 |
Origin | Guangdong, China(Mainland), | HS Code | 8419899090 |
1. Introduction
- For paint, coating, pigment, inks,pigment,detergent,Lithium anode paste, textile auliliary, etc.
- Combine milling and dispersing function.
- Energy saving
- High efficiency, easy operation, maintenance, cleaning and changing color.
- Applicable for independent tank operation and high/ low viscosity paste.
2. Main Features
- Configure with qualified Inverter, various speed control
- Hydraulic lifting, can be moved around
- Integrate dispersing and grinding in one process
3. Function selection
- Imported or domestic top brand inverter for option
- Custom-made design is available, such as Ex-proof, vacuum, sealed operation;
- Belt or not clamping for optional.
4. Technical data
Type | FD-45 | FD-55 | FD-75 | FD-90 | FD-110 | FD-132 |
Power(kw) | 45 | 55 | 75 | 90 | 110 | 132 |
Speed(rpm) | 0-1450 | 0-1450 | 0-950 | 0-950 | 0-950 | 0-950 |
Dia. of dispersing plate(mm) | 400 | 450 | 500 | 550 | 600 | 700 |
Lifting height(mm) | 1600 | 1600 | 1800 | 1800 | 2100 | 2300 |
6. Our service
- Engineers available to service machinery overseas.
- Technological support.
- Guarantee: 1 year.
- Custom-made is OK for us.
8. Why us?
1. Experienced workforce: more than 17 years
2. Excellent quality range of industrial process equipment ,80% materials and components are purchased from 3M, ABB, Siemens, Panasonic, Schneider
3. Strict quality controls
4. Good reputation in industry.
5. Customized packaging
6. Simple ordering process
7. Easy payment modes
8. Prompt delivery
9. Have a Professional after-sales service engineering team
9. Certificates
