anti-corrosion horizontal sand mill high speed for plant Jinzong Machinery
1. The new series of powder mixing equipment mainly use horizontal sand mill materials.
2. powder mixing equipment can deeply convince the client of its merits.
3. At the most competitive price, Guangdong Jinzong Machinery Co., Ltd. recommends cost-effectivepowder mixing equipment for buyers.
*Description:
Three rollers mill is mainly used for paint, ink, plastic, paint, food and other paste materials, especially suitable for grinding high viscosity and particle size of fine products. Roll is made of chilled alloy cast iron centrifugal casting, so the crystal phase is closely , high strength, the surface has high hardness and wear resistance, and is provided with a cooling system.
The machine by rotating the handwheel adjustment of the horizontal direction of the three rollers between the gap and the roller surface of jiga and different speed friction to grind dispersing effect.
Packaging & Shipping: Outer packing: plywood case; Inner packing: PE film wrapping overall; FOB port: Guangzhou or Shenzhen
| Model | S65 | S150 | S260 | S405 | SM405 | |
| Roller dia.(mm) | 65 | 150 | 260 | 405 | 405 | |
| Working length(mm) | 125 | 300 | 675 | 810 | 810 | |
| Speed | Slow(r/min) | 26 | 26 | 19.1 | 12.2 | 14.25 |
| Middle(r/min) | 70 | 70 | 54.5 | 37.6 | 44 | |
| Fast(r/min) | 145 | 145 | 155.3 | 116 | 135.5 | |
| Motor(kw) | 0.55 | 2.2 | 7.5 | 15 | 15 | |
| Size(mm) | 410×550×450 | 1010×930×1000 | 1645×1350×1100 | 2100×1950×1350 | 2290×1950×1350 | |
| Weight(kg) | 85 | 550 | 2200 | 5000 | 5200 | |
Company Features
1. Guangdong Jinzong Machinery Co., Ltd. is an internationally competitive enterprise engaged in the field of powder mixing equipment .
2. Guangdong Jinzong Machinery Co., Ltd. adopts high technology to guarantee high quality of powder mixer .
3. Guangdong Jinzong Machinery Co., Ltd. would like to grow up together with our customers and achieves mutual benefit. Call now! Guangdong Jinzong Machinery Co., Ltd. will strive to be recognized by the society, and become a national champion for producing powder mixer machine . Call now! Guangdong Jinzong Machinery Co., Ltd. has gradually cultivated and formed the entrepreneurial spirit of horizontal sand mill . Call now! Guangdong Jinzong Machinery Co., Ltd. strives to structure dry powder mixer as its service notion. Call now!
