high quality vacuum emulsifying mixer wholesale for nanometer materials
1. All shapes of stainless mixing tank can be adjusted according to customers' demands.
2. With the implementation of the improved quality inspection system, the product quality is guaranteed.
3. stainless mixing tank has a high performance and vacuum emulsifying mixer .
4. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.
Our vacuum homogenizing emulsifying mixer combines the newest-developed Germany technology and world-advanced unique function, its main components are imported originally from Germany. With new-structure, superior function, it is with fixed high-efficiency homogeneous emulsifier at the bottom, The complete-obscuration vacuum status with inner recycle system, All these make it very suitable for all kinds the production of cream and skin milk , and Compared to the traditional variety of emulsification equipment ,it has greatly improved the production efficiency and goods quality.
The vacuum homogenizing emulsifying mixer combines is developed on the basis of JRGD/Z, it is with fixed high-efficiency homogeneous emulsifier at the bottom, the emulsifying cover use the hydraulic pressure ascending, and main boiler fixed or can be design to the dumping ,the electrical control system with manual button control ,non-PLC and touch screen, the price is moderate.so it is very suitable for the high-efficiency production of various kinds of cream products.
*DEFINITION OF VACUUM HOMOGENIZING MIXER:
It mean that when the materials are under the vacuum condition, it makes use of the high shear emulsifier to distribute one or several phases to another continuous phase rapidly and evenly. The materials will be processed in the narrow space between stator and rotor by strong energy of motion produced by the mechanical effect. By the operation of hydraulic shearing, centrifugal extruding, impacting, breaking and turbulence for over thousand times per minute, the materials will be dispersed and emulsified instantly and evenly. After reciprocating circulation at high frequency, the fine finished products of stable and high quality without bubbles will be achieved.
| Model | Volume of main pot (L) | Emulsifying motor | Mixing motor | Oil & water pot capacity (L) | Dimension (mm) | Weight (kg) | ||
| Power (KW) | Speed (rpm) | Power (KW) | Speed (rpm) | |||||
| JRK-50 | 75 | 3 | 0-3000 | 0.75 | 0-74 | 45/65 | 2400*2100*1900-2500 | 1600 |
| JRK-75 | 100 | 3 | 0-3000 | 1.1 | 0-74 | 45/75 | 2600*2500*2000-2700 | 1700 |
| JRK-100 | 130 | 4 | 0-3000 | 1.5 | 0-74 | 70/100 | 2600*2700*2050-2800 | 1800 |
| JRK-200 | 260 | 5.5 | 0-3000 | 2.2 | 0-74 | 120/190 | 2900*3000*2400-3350 | 2300 |
| JRK-300 | 375 | 7.5 | 0-3000 | 3 | 0-74 | 150/260 | 3000*3200*2600-3600 | 2500 |
| JRK-500 | 620 | 11 | 0-3000 | 4 | 0-63 | 300/460 | 3500*3400*2800-4000 | 3300 |
| JRK-1000 | 1250 | 15 | 0-3000 | 5.5 | 0-50 | 620/900 | 4100*4100*3600-5100 | 5000 |
*MAIN COMPOSITION of Vacuum homogenizing emulsifying mixer:
The vacuum emulsifying mixer is mainly composed of water pot, oil pot, emulsifying pot, vacuum system, lifting system(optional),electric control system(PLC is optional),operation platform, etc.
*Vacuum homogenizing emulsifying mixer performances and features:
◪ High efficient emulsifier: it is a high efficient German compound homogeneous emulsifier with six-layer shear teeth of special structure, shearing more times, transient partial pressure up to 100Mpa above .its emulsification effect for materials which goes through the emulsifier is dozens of times than that of common ones.
◪ Precision motion mechanism and cooling system: high efficiency, power loss is small, heterogeneous devices can work long time, the application of special process requirements.
◪ Dead space-free multi-functional flow disturbance stirring system: it may effectively improve the stirring rate and mixing effects;
◪ Production of non-dead, out of less material residue: the JRKA homogeneous emulsifier type on the same machine, than the other types of emulsion is better;
◪ The cover of the main boiler can lift : to ensure that maintenance and cleaning easy;
◪ All lifting system uses hydraulic mechanism to ensure the smooth movement, accurate, and security;
◪ Manual control, operation and easy maintenance.
*Vacuum homogenizing emulsifying mixer application:
The emulsifying effect is more prominent for materials of high base viscosity and high solid content.
This machine is GMP as well as FDA standard, and is widely used in the high efficiency production of creams and ointment in cosmetics, pharmacy and chemicals. The product is widely applied in daily chemical care products, biopharmaceutical industry, food industry, paint and ink, nanometer materials, petrochemical industry, printing and dyeing auxiliaries, pesticide, fertilizer, fine chemical industry, etc.
