3 Stage Inline Homogenizer Pump Ex-Circulation Emulsifying Pump

Inline Homogenizer mainly used in Pharmaceutical, Chemical,Food ,Paint and Allied Industry Inline Homogenizer generally comes in different stages Single Stage ,Two Stage, Three stages and Four Stage consider reduction in particles size.



3 stage Inline Homogenizer pump ex-circulation Emulsifying pump is a complex but efficient compared to other process methodologies providing quality particle reduction while keeping up a continuous supply of material.
The four-stage tool consists of four concentric rows of cutting head (stator), and four consecutive impeller section (rotor). As the rotating blades pass each opening in the stator, they mechanically cut particles and material, the material is expelled at high velocity into the surrounding mix, creating shear. As fast as the material is expelled, more is drawn into the rotor/stator, which promotes continuous flow and fast mixing. The complete Mixer works as a self-pumping machine based on the centrifugal force created. The material passes from each tool in a sequence that has reducing slot sizes to ensure that the right homogenization is achieved as per the requirement as it exits the main work head.
