Product Information
Customer Reviews

Model NO.	FS	Layout Type	Verticle
Mixing Drum Shape	Disc	Additional Capabilities	Milling, Coating
Operating type	Continuous Operating	Condition	New
Name	Double Shaft Disperser	Cylinder Capacity	100L~3000L
Brand Name	Jinzong Mahcinery	Place of Origin	Guangdong, China (Mainland)
Voltage	380V 50Hz	Trademark	Jinzong Machinery
Transport Package	Plywood Case	Specification	CE, SGS, ISO9001
Origin	Guangdong	HS Code	8479820090

Product Description
The series of equipment are applied to the dissolution, mixing and dispersion of materials in many industries such as painting, dyestuff, pigment, medical, papermaking and other industries. The equipment is characterized by minimum include air during mixing and dispersion, perfect solid-liquid mixing and dispersion effect, and fast dissolution and fine particles during high-and medium-speed dispersion process

Features:
1. It has clamp device to fix vessel/container when under working process.
2. This model is more stable of working with vessel/tank than common type.
3. With variable running speed.
4. With frequency inverter to control the shaft mixing speed.

Technical parameter:
1. Motor: Alternative motor (Siemens, ABB, flameproof type is optional )
2. Power: From 1.5KW to 132KW
3. Power Supply: 380V/50Hz, 3P (voltage can be customized )
4. Speed control: with frequency inverter to realize various speed control
5. The part contacting with materials is: SUS304 or SS316L
6. Supporting frame: Q235-A
7. Height adjustment: Hydraulic lifting
8. with belt clamp, manual steel clamp or pneumatic clamp device.

Model	Plate Diameter of Dispersed(mm)	Motor Power(mm)	Speed(rpm)	Pump Power(kw)	Lifting Height(mm)
FS4	200	4	1~1450	0.55	900
FS5.5	200	5.5		0.75	1000
FS7.5	250	7.5		0.75	1000
FS11	250	11		0.75	1000
FS15	250	15		1.1	1200
FS18.5	300	18.5		1.1	1200
FS22	300	22		1.1	1200
FS30	350	30	1~1200	1.1	1200
FS37	350	37		1.5	1200
FS45	400	45		1.5	1200
FS55	400	55		1.5	1200

Applications:
   • Coatings
   • Paints
   • Dye Stuffs
   • Carbon Dispersions
• Printing Inks
    • Silicone Coatings
   • Paper Coatings
• Photographic Inks
    • Pigments
   • Dispersions
   • Fine chemicals
*Packaging& Shipping
1> Outer packing: plywood case
2> Inner packing: PE film wrapping overall
*Our Service
Pre-sales service:
1> Engineering design
2> Equipment model selection guide
3> equipment machinig
After-sales service:
1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free.
2> Provide professional after-sales service engineers to abroad installation and debugging.
*Company Information
We are a professional manufacturer of cosmetic,chemical& pharmaceutical machinery and equipment more than 17 years .Product lines range from:
1> Cosmetic Machinery: water treatment ,vacuum emulsifying machine,liquid detergent mixing machine,storage tank,solid soap making machine,perfume making machine, filling machine etc.
2> Chemical Machinery: reactor, mixing equipment,separation equipment, storage tank etc.
3> Pharmaceutical Machinery: vacuum ointment machine,sanitary stainless reaction pot,alcohol deposition can, collocation tank etc.
Why Choose Jinzong Machiney?
1. More than 17 years in Cosmetic and cheimical industry
2. Quality, 80% materials and components are purchased from 3M, ABB, Siemens, Panasonic, Schneider
3. Good reputation in industry.
4.Have a Professional after-sales service engineering team
5.Large scale and strong strength

The product requires little repairs and maintenance. This will significantly help avoid any production delay and keep projects running on time. It is resistant to breakage with its sturdy frame. The use of this product can help reduce the use of energy or power amount, which directly contributes to the cutting costs of manufacturers. It is resistant to breakage with its sturdy frame.
